Operating Limits:

Max. liquid temperature: 35℃

Min. well diameter: Φ 100mm

Max. immersion depth: 30m

Max. sand content: 0.15%

Continuous duty

Motor:

Two-Pole induction motor (n=2900r.p.m.)

Built-in thermal overload protector with automatic reset

Insulation Class B

Protection IPX8

Material:

Pump casing:Stainless Steel

Impeller:Plastic (POM)

Motor shaft:Stainless Steel

Diffuser:Plastic (PC)

Double mechanical seals:

Pump base:One: Silicon Carbide / Graphite

  Another: Ceramic / Graphite

Pump base:Plastic

Discharge body:Plastic

Product Advantages:

Integrated pump control

Integrated dry run protection

Compact design

Medium-cooled motor

Corrosion-resistant

Product Description:

The COM is a multistage, medium-cooled submersible pump for garden and domestic water

supply. It can be used to reliably supply rain water from a rainwater storage tank for toilets,

washing machines and garden watering. The intelligent pump controller recognizes if the pump

is running dry. In this event the pump will try to start again, if there is still no water available

the pump turns off. This all guarantees safe operation and high efficiency. The electronics also

protects the pump against defects in the non-return valve that generally occur due to dirt or

sand encrustations.

The advanced submersible pump concept incorporates many years of proven pump technology

with a sophisticated control to produce a compact and highly reliable product.
