Operating Limits:

Max. liquid temperature: 35℃

Max. immersion depth: 20m

Max. sand content: 0.15%

Continuous duty

Motor:

Two-Pole induction motor (n=2900r/min) φ 130

Built-in thermal overload protector with automatic reset

Insulation Class F

Protection IPX8

Single phase model with floating switch

Material:

Pump casing: AISI 304 Stainless Steel

Impeller and diffusers: Plastic (PPO)

Shaft: Stainless Steel

Double Mechanical seals separated by an oil chamber

Mechanical seal: Ceramic / Graphite

Application:

These pumps are used in lifting and pressurisation systems

for water from primary collection tanks or wells and are suitable

for providing pressurised water in domestic systems, smallscale farming and sprinkler systems for gardens and vegetable

gardens. The pump is extremely silent and this feature makes

it suitable for use with pressurisation systems in unventilated

rooms or in areas prone to flooding.
