Operating Limits:

Max. Liquid temperature: 0℃~50℃

Max. ambient temperature: 50℃

Continuous duty

Motor:

Two-Pole induction motor(n=2900r.p.m.)

Insulation Class F

Protection Class IP54

Single phase version built-in thermal protection

Standard voltage: 1x220-240V

3x220-240V/380-415V

Material:

Suction part and discharge part: Cast iron

Impeller: Plastic

Diffuser: Plastic

Motor Shaft: Stainless steel

Applications:

Thin, clean, non-flammable and non-explosive

liquid containing no solid granules and fibres

Garden sprinkler, rain water collection

Pressure boosting of tank

Air-conditioning and cooling system, industrial

washing and other special applications
