Liquid temperature:

Normal temperature type +15℃~+70℃

Hot water type + 70℃ ~105℃

Max. ambient temperature: 40℃

Max. operation pressure: 10 bar

Max. inlet pressure is limited by Max. operation pressure

Continuous duty

Motor:

Motor:Permanent Magnet Brushless DC Motor(Without Hall)

Controller:62bit MCU/FOC/Sine Wave Current/MPPT

Controller Shell:Die-cast Aluminum

Materials:

Pump body, back-cover, impeller, shaft and

guide plate in AISI 304

Bracket and motor casing: Aluminum

Mechanical seal: Ceramic / Graphite / NBR

Application:

The pumps are suitable for transporting clean media whcih

are non-aggressive to stainless steel AISI304 or AISI316.

Water supply systems

Pressure boiler feeding

Pure water treating systems

Pharmaceutical & food stuff

Refining Chemical industries

Washing and sprinkling
