Operating Limits:

Max. depth: 5m

Max. fluid temperature: 40℃

Max. ambient temperature: 40℃

Continuous duty

Motor:

Two-Pole induction motor (n=2900 r/min)

Insulation Class B

Protection IPX8

Material:

Pump body:AISI 304 Stainless Steel

Impeller:AISI 304 Stainless Steel

Motor shaft:AISI 304 Stainless Steel

Motor sleeve:AISI 304 Stainless Steel

Mechanical seal:Ceramic / Graphite

Application:

MCM submersible pump is designed to handle

dirty water and sewage in domestic and civil

applications. It is fitted with a stainless steel double

vane impeller, and is suitable for pumping liquids

containing suspended solids, including short fibres.

It is particularly recommended for the transfer

of domestic sludge, refluent and surface water,

water mixed with mud in areas such as: domestic

housing, industrial applications and underground

car parks. This pump is particularly dependable in

fixed installations intended for automatic use.
